smartmicro DRVEGRD 171
Meet smartmicro's extra-long-range automotive radar. DRVEGRD 171, introduced with three different waveform modes, has a range of 0.2m to a maximum of 240m. Its wide beam provides a 100° field of view, and excellent angular separation of 2° in all available modes. The radar assures an outstanding detection for front applications on autonomous shuttles and taxis or industrial vehicles.
Designed for ASIL-B compliance, the sensor enables the integration into safety systems and meets the challenges of Advanced Driver Assistance Systems (ADAS) and the L2+ autonomous vehicles market. It fills the gap between state-of-the-art ADAS radars and 4D imaging radar sensors, at an attractive cost.
DRVEGRD 171 Product Sheet
- Extra-long range of 240m
- Wide field of view of 100°
- Pixel-High Definition (PxHD) resolution: true 2° angular separation
- 4 Dimensions (4D): range, speed, azimuth, and elevation angle
- Time and acquisition synchronization
- Plug-and-play 360° sensor data fusion
- Dual CMOS cascaded RF chips, 48 channels
Performance |
Long Range Mode | Medium Range Mode | Short Range Mode |
|---|---|---|---|
| Operating Frequency | 76...77 GHz 4 center frequencies |
76...77 GHz 2 center frequencies |
76...77 GHz 1 center frequency |
| Detection Range Passenger Car | 240 m / 787.4 ft | 100 m / 328.1 ft | 40 m / 131.2 ft |
| Detection Range Min...Max | 1.2...240 m / 3.94...787.4 ft | 0.5...100 m / 1.64...328 ft | 0.2...40 m / 0.66...131.2 ft |
| Range Separation | ≤ 2.4 m / ≤ 7.87 ft |
≤ 1.0 m / ≤ 3.28 ft | ≤ 0.4 m / ≤ 1.31 ft |
| Range Accuracy | ≤ 0.6 m / ≤ 1.97 ft |
≤ 0.25 m / ≤ 0.82 ft | ≤ 0..1 m / 0.33 ft |
| Speed Min...Max | -400...+200 km/h / -249....+124 mph |
-250...+200 km/h / -155...+124 mph | |
| Speed Separation | < 0.26 m/s | < 0.52 m/s | |
| Speed Accuracy | < 0.07 m/s | < 0.14 m/s | |
| Field of View Azimuth | -50…+50° | ||
| Field of View Elevation | -10…+10° | ||
| Angle Accuracy Azimuth | ≤ 0.5° | ||
| Angle Accuracy Elevation | ≤ 0.5° | ||
Mechanical |
|||
| Weight | < 300 g / < 10.58 oz | ||
| Dimensions | 97.5 ×143 × 26 mm / 3.84 × 5.63 × 1.02 in | ||
General |
|||
| Update Cycle Time | ≤ 50ms |
≤ 50ms | ≤ 32ms |
| Operating Voltage / Power Supply | 7...32 V / < 7 W | ||
| Operating Temperature | -40...+85°C / -40...+185°F | ||
| Interfaces | 100 or 1000BASE-T1 Ethernet 1GBit (2-wire); 2×CAN FD 5MBit/s | ||
| Connector | MX4 Moles Series | ||
| IP | IP 67 | ||
